Handheld Sonic Dispersion Device

SXDRADDH

NewGeneration Handheld Directional Acoustic Dispersion Device

A newgeneration handheld directional acoustic dispersion device is a nonlethal acoustic weapon. It uses internationally advanced technology to focus sound wave beams within a directional range of ±15°.

Its closerange dispersion function delivers intense noise to target groups, stimulating the auditory organs and central nervous system to induce nausea, irritability, dizziness, and temporary loss of resistance. Its longrange hailing function can transmit clear voice commands over a distance of 1 kilometre.

The device supports functions including dispersion, expulsion, subdual, security alerting, warning, evacuation guidance, longdistance communication and instruction. It provides effective deterrence, early warning and proactive prevention capabilities.

Maximum Sound Pressure Level: ≥ 141 dB

Frequency Range: 400 Hz – 6 kHz

Acoustic Beam Constraint Angle: ＜ ±15°

Speech Intelligibility: Greater than 80% at 800 metres

Transmission Distance: ＞ 1000 metres

Battery Life: ≥ 4 hours

Gross Weight: ＜ 2.5 kg

Hailing Modes: Manual voice, recorded announcement, audio input, wired and wireless hailing

Audio Playback: Multiple audio sources, loop playback

Dimensions: ＜ 400 mm (L) × 200 mm (W) × 250 mm (H)

Ingress Protection Rating: IP65

Operating Temperature: -40°C to 50°C

Storage Temperature: -45°C to 55°C

Rain Test: Compliant with GB 167962009 Safety Requirements and Test Methods for Security Alarm Equipment

Damp Heat Test: Compliant with GB 167962009 Safety Requirements and Test Methods for Security Alarm Equipment

Salt Spray Test: Compliant with GB 167962009 Safety Requirements and Test Methods for Security Alarm Equipment

Vibration Test: Compliant with GB 167962009 Safety Requirements and Test Methods for Security Alarm Equipment

Impact Test: Compliant with GB 167962009 Safety Requirements and Test Methods for Security Alarm Equipment

Adopts internationally advanced technologies including directional acoustics, highefficiency electroacoustic conversion, dynamic transducers and highintensity acoustic emission.

Compared with advanced foreign products, it features lighter weight, smaller size, easy portability, strong antiinterference performance, high sound pressure level, long effective range, high speech intelligibility, low power consumption, strong deterrent effect, long operating duration and simple operation.

With militarygrade quality, it meets the requirements of various harsh environments including extreme temperatures and high altitudes.

Riot Control and Emergency Response

CounterTerrorism and Stability Maintenance

Public Security Patrol

Search and Rescue

Prison Administration

Border Inspection

Border Patrol

Emergency Rescue

Military and Police Drills

Disaster Relief

Training and Tactical Communication

Forest and Grassland Patrol

OnSite Command

Political and Publicity Work

Suicide Intervention

Emergency Broadcasting

Traffic Control

Evacuation Guidance

Widely used by military forces, armed police, public security, border defence, prisons, emergency rescue services, fire departments, forestry and grassland authorities, customs and other agencies.
